Supplier AH-5000W listing installation with a wind turbine beside a telecom tower and solar modules

Supplier installation reference from the AH-5000W listing.

Supplier-reference photography. Confirm the final equipment appearance and included accessories with your quotation.

Wind Turbines / Pitch-controlled turbines

5 kW Pitch-Controlled Wind Turbine

Technical reference AH-5000W

A variable-pitch option for hybrid installations and isolated loads. The rotor and controlled blade pitch support project-specific generation, braking and battery or grid interface planning.

Rated power: 5 kW
Rotor diameter: 5.6 m
Rated wind: 11 m/s
Control: Variable pitch

Request a quotation Download specifications ↓

Configuration, availability, certification scope and commercial terms are confirmed at quotation.

PRODUCT SPECIFICATIONS

The details
behind the configuration.

Values below follow the referenced model or explicitly stated model family. Review the final datasheet, rated conditions and supply scope before procurement.

Technical reference & verification

Anhua AH-5000W supplier parameter table on Made-in-China

Reference model: AH-5000W
Reviewed: 2026-10-15

View original technical reference ↗

Detailed AH-5000W table used. Start-up speed differs from the page's general prose; confirm final variant. Tower, controller and inverter are separately configured.

5 kW Pitch-Controlled Wind Turbine reference specifications
Rated power	5,000 W
Maximum power	6,500 W
Rotor diameter	5.6 m
Blades	Reinforced fibreglass / 3
Rated wind speed	11 m/s
Rated rotation	240 rpm
Working wind range	3–30 m/s
Start-up wind speed	3 m/s
Survival wind speed	60 m/s
DC system options	120 / 240 V
Speed regulation	Pitch control
Stop method	Manual brake + pitch control
Generator	Three-phase permanent magnet
Turbine weight	400 kg
Listed tower height	8 m

Published reference values are not a substitute for the final selected-model datasheet and project design.

CONFIGURATION HIGHLIGHTS

Equipment with
a project in mind.

Variable-pitch regulation
Three-blade fibreglass rotor
Hybrid-system integration option

APPLICATION STARTING POINTS

Connect the product
to the site.

Remote telecomWind-solar hybridsIsland energy systems

The complete system must account for site loads, electrical interfaces, environmental limits and local installation requirements.

Explore the planning guide

FROM PRODUCT TO PROJECT

Let’s confirm the
right configuration.

Share your country, quantity, electrical requirements, installation environment and delivery plan. Ask for the final datasheet and supply scope for this reference.

Discuss this product on WhatsApp ↗
