Complete horizontal-axis wind turbines with three-blade rotors, nacelles, tail vanes and full towers at a supplier installation site

Complete wind-turbine installation reference from the AH-10KW supplier listing; ordered tower and electrical scope are confirmed for each project.

Supplier-reference photography. Confirm the final equipment appearance and included accessories with your quotation.

Wind Turbines / Pitch-controlled turbines

10 kW Wind-Solar Hybrid Turbine

Technical reference AH-10KW

A larger small-wind platform for hybrid power schemes with a suitable measured wind resource. Pitch regulation and electrical braking support a coordinated design with solar generation, storage and the required conversion equipment.

Rated power: 10 kW
Rotor diameter: 7.78 m
Rated wind: 11 m/s
DC options: 240 / 500 V

Request a quotation Download specifications ↓

Configuration, availability, certification scope and commercial terms are confirmed at quotation.

PRODUCT SPECIFICATIONS

The details
behind the configuration.

Values below follow the referenced model or explicitly stated model family. Review the final datasheet, rated conditions and supply scope before procurement.

Technical reference & verification

Anhua AH-10KW supplier listing on Made-in-China

Reference model: AH-10KW
Reviewed: 2026-10-15

View original technical reference ↗

AH-10KW model table used. Survival wind speed is a supplier design claim, not continuous operating wind. Tower engineering and electrical interfaces require project verification.

10 kW Wind-Solar Hybrid Turbine reference specifications
Rated power	10,000 W
Maximum power	12,000 W
Rotor diameter	7.78 m
Blades	Reinforced fibreglass / 3
Rated wind speed	11 m/s
Rated rotation	180 rpm
Working wind range	3–30 m/s
Start-up wind speed	2.5 m/s
Survival wind speed	60 m/s
Working DC voltage	240 / 500 V
Speed regulation	Pitch control
Stop options	Manual / automatic electrical brake
Generator	Three-phase permanent magnet
Turbine weight	450 kg

Published reference values are not a substitute for the final selected-model datasheet and project design.

CONFIGURATION HIGHLIGHTS

Equipment with
a project in mind.

Pitch-controlled rotor
Electrical braking option
Higher-voltage system options

APPLICATION STARTING POINTS

Connect the product
to the site.

Farm energyHybrid microgridsRemote commercial sites

The complete system must account for site loads, electrical interfaces, environmental limits and local installation requirements.

Explore the planning guide

FROM PRODUCT TO PROJECT

Let’s confirm the
right configuration.

Share your country, quantity, electrical requirements, installation environment and delivery plan. Ask for the final datasheet and supply scope for this reference.
